Bandpass & Bandstop Filters

The Microphase Bandpass Filters offer six different design types, which have a range of capabilities and options. These filters cover frequencies from 100 MHz to 90 GHz and bandwidths of up to several octaves. They maintain rejection levels exceeding 90 dB, VSWR from 1.2:1 to 2.0:1 and an insertion loss as low as 0.35 dB.

Microphase Band Reject Filter cover the frequency range of 10MHz to 40 GHz with narrow to wide customer specified frequency stopbands. Typical notch attenuation is in the 80-100 dB range while maintaining low loss passbands above and below the specified notch frequencies.
